LLL型立式煤泥离心脱水机 Vertical Coal Slime Centrifugal Dehydrator
用途：在选煤厂主要用于回收煤泥水中料度》0.15mm的粗煤泥。
Application: This type of centrifugal dehydrator is mainly used to recycle coarse coal slime with particle side of not smaller than 0.15mm in the coal slime water.
技术特点：处理能力为20-50t/h，产品外在水分为14%-16%。随煤质的不同，入料度组度成不同，离心机的处理能力有很大的不同。
Technical Characteristics: Handling capacity: 20-50t/h; surface moisture of products: 14%-16%. With the difference in coal quality, the particle size group is different and the handling capacity of centrifugal dehydrators is greatly different.
| 型号规格 | LLL930 | LLLL1030 | LLL1200 | |
| 回收粒度 | mm | >0.15 | >0.15 | >0.15 |
| 入料浓度 | % | <40(>60) | <40(>60) | <40(>60) |
| 处理能力 | t/h | 20-30 | 25-35 | 30-35 |
| 产品外在水分 | % | 12-16 | 12-16 | 12-16 |
| 筛篮大端直径 | mm | 930 | 1030 | 1180 |
| 筛篮转速 | r/min | 600 | 520 | 534 |
| 筛篮半锥角 | (0) | 30 | 30 | 30 |
| 筛网缝隙 | mm | 0.25、0.35、0.5 | 0.25、0.35、0.5 | 0.25、0.35、0.5 |
| 主电机功率 | kw | 37 | 45 | 75 |
| 润滑电机功率 | kw | 0.75 | 1.1 | 1.1 |
| 外型尺寸 | mm | 2780×2080×2450 | 3010×2250×2515 | 3243×2420×2705 |
| 质量 | t | 4.65 | 6.47 | 7.97 |
